The Omni IQ™ G720 is the advanced, connected differential pressure monitor engineered for ICRA 2.0 compliance in the most demanding critical environments. Its exclusive TriZone™ capability tracks three zones plus a reference point — covering containment, anteroom, and corridor from a single unit — while automatically logging every reading and alert for defensible, audit-ready documentation accessible from any phone, tablet, or computer.
Key Features
- TriZone™ monitoring — containment, anteroom, and corridor from one device
- ICRA 2.0 compliant — meets and exceeds infection control requirements
- Industry-leading accuracy: ±0.0007 in. W.C.
- Instant alerts via web, mobile app, email, and SMS with auto-escalation
- Automated, audit-ready reporting exported on demand
- Wi-Fi + cellular connectivity with 5 years of free cellular service included
- Up to 15-day rechargeable battery life
- FlexGo™ universal mounting works with any containment
- Complimentary first-year premium software (remote control, shareable projects, predictive alerts, unlimited data retention)
Applications: healthcare construction & renovation, infection control in occupied facilities, temporary containment, abatement & remediation, critical room pressure monitoring, and mobile HEPA cart integration.
Specifications
| Model Number | IQ-G720 |
| Monitor Zones | 3 (plus reference point) |
| Operating Pressure Range | ±0.10 in. W.C. |
| Accuracy | ±0.0007 in. W.C. |
| Resolution | 0.0001 in. W.C. |
| Long-Term Stability | ±0.005 in. W.C. per year |
| Overpressure | 120 in. W.C. |
| Pressure Media | Air or non-conductive, non-explosive gases |
| Pressure Fittings | 3x port for 1/8" ID tubing |
| Display | 5" touchscreen |
| Power | 24VDC (adapter provided) |
| Battery Life | Up to 15 days |
| Connectivity | Wi-Fi + Cellular (5 years included) |
| Local Data Storage | 64 GB |
| Operating Temp | 32°F to 104°F (0°C to 40°C) |
| Humidity | 10% to 90% RH, non-condensing |
| Dimensions (Outer Enclosure) | 12.4" x 10.4" x 5.3" |
| Weight | 8.2 lbs |
| Audible Alarm | 90 dB |
| Regulatory | FCC Part 15.107 Class A; ISED Canada ICES-003 Class A |
What's in the Box
- Omni IQ™ G720 unit
- FlexGo™ bracket
- Tubing kit
- Power adapter
- Quick start guide
- Calibration certificate
Software Plans
Basic (Free): Live monitoring & alerts, 6-month data history, project & device management.
Professional ($199/year per device): Includes annual NIST-traceable calibration ($169 value), unlimited data history, shared projects, smart alert escalation, and remote device control.
Specifications
The Omni IQ™ G720 is the advanced, connected differential pressure monitor engineered for ICRA 2.0 compliance in the most demanding critical environments. Its exclusive TriZone™ capability tracks three zones plus a reference point — covering containment, anteroom, and corridor from a single unit — while automatically logging every reading and alert for defensible, audit-ready documentation accessible from any phone, tablet, or computer.
Key Features
- TriZone™ monitoring — containment, anteroom, and corridor from one device
- ICRA 2.0 compliant — meets and exceeds infection control requirements
- Industry-leading accuracy: ±0.0007 in. W.C.
- Instant alerts via web, mobile app, email, and SMS with auto-escalation
- Automated, audit-ready reporting exported on demand
- Wi-Fi + cellular connectivity with 5 years of free cellular service included
- Up to 15-day rechargeable battery life
- FlexGo™ universal mounting works with any containment
- Complimentary first-year premium software (remote control, shareable projects, predictive alerts, unlimited data retention)
Applications: healthcare construction & renovation, infection control in occupied facilities, temporary containment, abatement & remediation, critical room pressure monitoring, and mobile HEPA cart integration.
Specifications
| Model Number | IQ-G720 |
| Monitor Zones | 3 (plus reference point) |
| Operating Pressure Range | ±0.10 in. W.C. |
| Accuracy | ±0.0007 in. W.C. |
| Resolution | 0.0001 in. W.C. |
| Long-Term Stability | ±0.005 in. W.C. per year |
| Overpressure | 120 in. W.C. |
| Pressure Media | Air or non-conductive, non-explosive gases |
| Pressure Fittings | 3x port for 1/8" ID tubing |
| Display | 5" touchscreen |
| Power | 24VDC (adapter provided) |
| Battery Life | Up to 15 days |
| Connectivity | Wi-Fi + Cellular (5 years included) |
| Local Data Storage | 64 GB |
| Operating Temp | 32°F to 104°F (0°C to 40°C) |
| Humidity | 10% to 90% RH, non-condensing |
| Dimensions (Outer Enclosure) | 12.4" x 10.4" x 5.3" |
| Weight | 8.2 lbs |
| Audible Alarm | 90 dB |
| Regulatory | FCC Part 15.107 Class A; ISED Canada ICES-003 Class A |
What's in the Box
- Omni IQ™ G720 unit
- FlexGo™ bracket
- Tubing kit
- Power adapter
- Quick start guide
- Calibration certificate
Software Plans
Basic (Free): Live monitoring & alerts, 6-month data history, project & device management.
Professional ($199/year per device): Includes annual NIST-traceable calibration ($169 value), unlimited data history, shared projects, smart alert escalation, and remote device control.
